Hydraulic Stone Splitters And Stone Processing Machine
- Type
- Hydraulic Stone Splitting Machine
- Usage
- Granite, Artificial Stone, Marble, Basalt, Limestone, Quartzite, Slate, Sandstone
BESTLINK
Contact SupplierMachinery Function Features
BASIC TECHNICAL PARAMETERS
| Parameter | Unit | brt70ton |
|---|---|---|
| Machine width (W) | mm | 1200 |
| Machine height (H) | mm | 2520 |
| Max. working width | mm | 400 |
| Max. working height | mm | 350 |
| Main Motor Power | kw | 11 |
| Max. Pressure | tons | 70 |
| Machine length (L) | mm | 1500 |
| Approximate weight | Kg | 3200 |
Software
|
Model No. |
BRT 320T-M |
BRT 160T |
BRT 70T |
BRT 40T |
BRT 20T |
|
Splitting pressure |
320T |
160T |
70T |
40T |
20T |
|
Max.splitting width |
1200mm |
500mm |
400mm |
240mm |
160mm |
|
Max.splitting height |
800mm |
550mm |
350mm |
320mm |
180mm |
|
Adaption of upper /lower blade |
36*20mm |
30*15mm |
20*10mm |
15*10 |
10*7mm |
|
Rated power |
22KW |
15KW |
11KW |
11KW |
7.5KW |
|
Rated voltage |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
|
Electric current |
42.5A |
30A |
22.6A |
22.6A |
15A |
|
Main oil cylinder data |
Φ400/Φ280-850 |
Φ280/Φ200-600 |
Φ200/Φ140-360 |
Φ160/Φ110-340 |
Φ110/Φ80-200 |
|
Oil advanced speed |
40mm/s |
76.6mm/s |
108mm/s |
167mm/s |
96mm/s |
|
Overall size(L*W*H) |
2370*1500*3840mm |
1970*1200*3300mm |
1500*1200*2520 |
1260*1000*2300 |
1145*1000*2030 |
|
Weight |
8000KG |
5300KG |
3200KG |
2900KG |
2300KG |
Processed Stone Photos

Components
Consumables
Operation Video
After-Sale
- Lead Time
- 25-45 dyas
- Warranty
- 12 months
- Install and Guarantee
- Third-party team installation
- Maintenance
- Regular guidance & maintenance, Remote troubleshooting
