Crusher and 3 output Separation System 250-80M3 from Italy

Favorites

Type: Rock Crushers, Jaw Crushers
Usage: Granite, Marble, Limestone, Sandstone

After-Sale

Warranty: 12 months

Supplier: TECNOPORRO s.a.s.
Location: Italy

Tecnoporro

Established: Dec 30,1989

Main Product: Water Tratment, Filter Press, Filter Bags, Systems Aspiration of dusts, Crusher and Separartor System

Contact Supplier

Machinery Function Features

The 250-80 series include Stone Crushers with Special Blades and related accessories, such us Separators, Tipper Containers, Conveyor Belts (and others) are designed to recycle raw materials and scraps from processing of stone, marble, granite, porphyry, quartz, ceramics, building demolitions, similar material and glass, in small and large size, reducing the fragmented output for every requirement. Crushing process: it takes places due to a compression with a direct eccentric mechanism between different special plates (fixed and mobile), actuated by a transmission with trapezoidal belts, which can assume different levels of adjustment. Benefits: reduce the space of the same waste with its reuse in gardening, mosaic, road fills, furnishings and so on. The 250-80M3 Model is composed of the Crusher and 3 output Separation System, simultaneously at the crushing occurs a sectioned division of the crushed output into three customizable parts, replacing grids according to every need.

BASIC TECHNICAL PARAMETERS

Technical Data
Parameter	Unit	250-80M3
Dimension LxWxH	mm	1200 x 800 x 1750
Weight	Kg	620
Feed opening width X depth	mm	250 x 120
Power	kw	4.5 (380/400V – 50/60Hz)
Max Output (capacity)	m³/ h	1.2
Loading Hopper	mm	250 x 300
Mobil Plate Level		9 adjustments
Size Output	mm	0 – 30/40
Size Output Separated	mm	3 outputs (standard) → 0 – 4 / 5 – 14 / 15 – 40

Processed Stone Photos

Components

Separation System M3

Tipping container C1

Tipping container C2

Detection sensor X

Conveyor belt PLUS

Lateral Staircase K
