Jaguar Screw Air Compressor For Drilling Rig
- Type
- Air Compressors, Generators
After-Sale
- Warranty
- 12 months
- Install and Guarantee
- Remote guidance installation, Third-party team installation
- Maintenance
- Online software upgrade
- Supplier
Zhengzhou Windbell Machinery Co., Ltd.- Location
China
Windbell
Established: Jan 01,2006
Main Product: Air Compressor
Contact SupplierYou may also like
Machinery Function Features
Comparing with single stage compression compressor, two stage compressor is closed to the maximum energy saving and isothermal compression, it can save energy more than 10%.
Two stage compression air end adopts two units of different size rotors, distributes pressure reasonably, reduces compression ratio and heat produced in process of compressing.
According to the working principle of compressor, isothermal compression is the most energy saving type. Two units of rotors is cooled by sprayed coolant which is with high cooling efficiency, actualize isothermal compression to save energy.
BASIC TECHNICAL PARAMETERS
| Parameter | Unit | WBS-45A/WⅡ | WBV-45A/WⅡ | WBS-55A/WⅡ | WBV-55A/WⅡ | WBS-75A/WⅡ | WBV-75A/WⅡ | WBS-90A/WⅡ | WBV-90A/WⅡ | WBS-110A/wⅡ | WBV-110A/WⅡ | WBS-132A/WⅡ | WBV-132A/WⅡ |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Type (Screw/Rotary/..) | Screw | Screw | Screw | Screw | Screw | Screw | Screw | Screw | Screw | Screw | Screw | Screw | |
| Configuration(Stationary/Portable) | Stationary | Stationary | Stationary | Stationary | Stationary | Stationary | Stationary | Stationary | Stationary | Stationary | Stationary | Stationary | |
| Power Source | AC Power | AC Power | AC Power | AC Power | AC Power | AC Power | AC Power | AC Power | AC Power | AC Power | AC Power | AC Power | |
| Lubrication Style | Lubricated | Lubricated | Lubricated | Lubricated | Lubricated | Lubricated | Lubricated | Lubricated | Lubricated | Lubricated | Lubricated | Lubricated | |
| Working Power | kw | 45 | 45 | 55 | 55 | 75 | 75 | 90 | 90 | 110 | 110 | 132 | 132 |
| Working Pressure | bar | 7~12 | 7~12 | 7~12 | 7~12 | 7~12 | 7~12 | 7~12 | 7~12 | 7~12 | 7~12 | 7~12 | 7~12 |
| Weight | Kg | 2100 | 2100 | 2200 | 2200 | 2300 | 2300 | 3500 | 3500 | 4000 | 4000 | 4200 | 4200 |
| Dimension LxWxH | cm | 205*120*170 | 205*120*170 | 205*120*170 | 205*120*170 | 205*120*170 | 205*120*170 | 280*160*180 | 280*160*180 | 280*160*180 | 280*160*180 | 280*160*180 | 280*160*180 |
| Cooling Method | Air or water | Air or water | Air or water | Air or water | Air or water | Air or water | Air or water | Air or water | Air or water | Air or water | Air or water | Air or water | |
| Free Air Delivery | m3/min | 10.3~8.1 | 10.3~8.1 | 13.0~10.2 | 13.0~10.2 | 16.2~13.4 | 16.2~13.4 | 20.5~15.1 | 20.5~15.1 | 24.5~16.0 | 24.5~16.0 | 30.0~19.5 | 30.0~19.5 |
| Outlet Diameter | DN65 | DN65 | DN65 | DN65 | DN65 | DN65 | DN80 | DN80 | DN80 | DN80 | DN80 | DN80 | |
| Voltage | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V |
